Description
Features:
- Safe and proven Lithium Titanium Oxide chemistry
- Extremely high cycle life (>40,000 cycles)
- High discharge rate (50C constant, 75C burst)
- Custom injection molded ABS case
- Actively balanced
- Fully machined 6061 aluminum busbars
- 18x 2/0 Inputs (Positive and Negative)
- 18x 2/0 Lug Mounting Spots (Positive and Negative)
- All hardware included (set screws and lug screws)
- Assembled in the USA
Specifications:
- Capacity - 45Ah
- Max Voltage - 16.2V
- Recommended Voltage - 15.6-16.0V
- Continuous Discharge - 2,250A
- Max Discharge - 3,375A
- Discharge Voltage Cutoff - 11V
Dimensions:
- Length - 18.82"
- Width - 10.77"
- Height - 6.55"
We strive to keep all models in-stock. Units are built and ready to ship.
True Amplifier Power Ratings*:
16.0V Charging (Recommended)
- 32,400W - Standalone (Burst <5s)
- 25,200W - Standalone (Burst <15s)
- 22,800W - Standalone (Constant)
- 24,000W - With Stock Alt
- 25,000W - With 200A Alt
- 26,000W - With 300A Alt
15.5V Charging
- 27,000W - Standalone (Burst <5s)
- 20,250W - Standalone (Burst <15s)
- 19,000W - Standalone (Constant)
- 20,200W - With Stock Alt
- 21,200W - With 200A Alt
- 22,200W - With 300A Alt
Cell Power Ratings**:
16.0V Charging (Recommended)
- 40,500W - Standalone (Burst <5s)
- 31,500W - Standalone (Burst <15s)
- 28,500W - Standalone (Constant)
- 30,000W - With Stock Alt
- 31,000W - With 200A Alt
- 32,000W - With 300A Alt
We DO NOT recommend charging below 15.2V. Premature failures resulting from undercharging are not covered by warranty.
* - True Amplifier Rating is the expected power support at 80% amplifier efficiency. This rating was added to better help customers understand their output support.
** - Cell Power Rating is the original power pulled from the battery before amplifier efficiency is calculated.
Please note: All lithium batteries will be shipped via UPS Ground. Batteries are shipped at 30% State-of-Charge and MUST BE CHARGED BEFORE USE.
